Main Features
Maximum Power Output MOSFET 50W x 4
Tuner RDS FM/AM tuner (24 presets)
Plays - RDS FM/AM Tuner (24 preset stations)
- Your iPod, iPhone, Android Smartphone
- Bluetooth audio
- Other music and video devices via the Aux-In
Via CD or DVD:
- MP3, WMA and AAC audio files
- DivX and MPEG-1,2,4 video files
Via USB:
- WMA, MP3, AAC, WAV and FLAC audio files
- MPEG4, WMV, DivX, H.264, MKV and FLV video files
- JPEG image files
Screen 7" WVGA, Anti-glare Touchscreen with Advanced Display Resolution
Installation Type 2-DIN integrated entertainment hub
Front Panel Motorised, fully detachable
Button Illumination RGB Colour Customisation (210,000 Colours)
DVD Region Code 4
Dual Zone Yes
MIXTRAX EZ Yes
Smartphone Ready Yes
AppRadio Mode Yes
Supported Apps Find all compatible apps on www.pioneer.eu/appradiomode
Bluetooth Ready Yes
Accessories Included:
- 1 Power connector
- 1 USB extension cables
- 1 External Bluetooth mic
Optional:
- ND-BC6 (Reverse camera)
Connections
Aux In Rear AV Aux-in
HDMI Yes (Optional HDMI cable required)
MirrorLink No
Input for rear camera Yes
ISO connector No
PAL/NTSC/SECAM Yes
RCA preouts 3 Hi-Volt (Front, Rear, Subwoofer)
High voltage output 4V
RCA video 2 Video Input (VCR / mini-jack AV)
Hard wired remote input Yes
USB input 2 Rear USB (1 Amp)
Video output Rear Video output
Screen Features
Selectable wide screen modes Yes
Auto display brightness & backlight adjustment Yes
Rear camera switching Yes
Angle adjustment Yes(Up/Down)
Audio Features
Advanced Sound Retriever Yes
Advanced Sound Retriever for Bluetooth Yes
Auto EQ Yes (requires optional CZX-5497A mic)
Dolby Digital Yes
Equaliser 13 band Graphic Equaliser
High Pass Filter Yes
Low Pass Filter Yes
Sonic Center Control Yes
Source Level Adjuster Yes
Cellular Telephone Auto Muting Yes
Apple Compatibility
Works with iPod Yes
Works with iPhone Yes
CarPlay Yes
Compatible Generations - iPhone 5/5s/5c/6/6+ (Use official Apple USB -Lightning cable for audio playback and CarPlay)
- iPhone 4/4s (Optional CD-IU201V cable required for audio/video)
- iPod/iPhone Music/Video Direct Control
Supported Functions - Siri Eyes Free
- Music playback
- Battery charging
- List browsing
- Album art
App Mode Yes
Android Compatibility
Works with Android Yes
Android Auto Yes
Compatible Generations Android Auto is compatible with Android smartphones using the lollipop platform. Please consult your smartphone provider for confirmation on computability.
Bluetooth Features
Parrot Bluetooth Module Yes
Hands-free calls Yes
Additional Bluetooth Features - Music streaming via A2DP & AVRCP 1.4
- Automatic Phone book transfer
- 1000 entries for up to 3 individual phones (each contact can hold up to 5 unique numbers)
- Simple Secure Pairing
Compatibility HFP/A2DP/SPP
